Process Monitoring

XARION powder bed fusion monitoring

Materials & Design 08/2021

Mutual comparison of acoustic, pyrometric and thermographic laser powder bed fusion monitoring

Authors:

Kai Gutknecht, Michael Cloots, et. al.

Contents:
  • The process monitoring capabilities of three distinctive sensors (XARION’s optical microphone, a pyrometer and a thermographic camera) were compared for laser powder bed fusion metal additive manufacturing
  • The optical microphone presents a sensitivity up to 40 times higher than the thermographic camera and is 15 times more sensitive than the pyrometer
PDF
LANE 2020

Proceedings of LANE 2020 Erlangen

In situ process monitoring by optical microphone for crack detection in Laser Metal Deposition applications

Authors:

Camilo Prieto, Roberto Fernandez, et.al.

Contents:
  • Contact-free crack detection in Laser Metal Deposition (LMD) applications in collaboration with AIMEN successfully documented
  • XARION’s optical microphone, Eta250 Ultra, enabled real-time monitoring of crack and process signals of additive manufacturing applications
PDF

Proceedings of SPIE LASE 2020 San Francisco

Air-coupled membrane-free optical microphone and optical coherence tomography keyhole measurements to setup welding laser parameters

Authors:

Nicolas Authier, Enzo Touzet, et. al.

Contents:
  • Accurate measurements of the welding depth could be demonstrated with XARION's sensor by the French Alternative Energies and Atomic Energy Commission (CEA)
  • The combination of Optical Coherence Tomography with airborne ultrasound data from an Optical Microphone is a promising match for in-line monitoring of laser welding processes
PDF

Bachelor Thesis University Ravensburg-Weingarten

Acousto-optical Process Control for Laser Ablation and Laser Welding

Authors:

Chen Peng

Contents:
  • The optical microphone has proven effective and invaluable as a measurement instrument during laser processes.
  • The measurements obtained are useful in:
    • the automated calibration of the optimum focus spot of a laser beam,
    • controlling the laser ablation quality in a production line without modifying the workpiece, and
    • identifying keyhole formation (or lack thereof) during laser welding processes.
PDF

LASER 06/2019

Akustische Überwachung für die Lasermaterialbearbeitung (German)

Authors:

Christian Schröter, Ryan Sommerhuber, et al.

Contents:
  • Contact-free monitoring of laser welding, cutting and structuring
  • Real-time determination of ideal focus position and unwanted zinc contamination
PDF

Ceramic Industry 02/2019

Non-Contact Ultrasound Diagnostics for the Ceramic Industry

Authors:

Fabian Lücking

Contents:
  • Detection of tiny cracks in ceramic workpieces with the help of XARION's optical microphone
  • Monitoring of acoustic emissions without the need for physically contacting the workpiece
PDF

Structual Control Health Monitoring Journal 03/2019

Online cracking detection by means of optical techniques in laser‐cladding process

Authors:

Aitor García de la Yedra, Michael Pfleger, et al.

Contents:
  • This paper shows that XARION’s sensor technology can be used for the in-process monitoring of a laser-cladding process.
  • Comparison of the optical microphone against other online monitoring systems for laser cladding processes
PDF

Laser Technik Journal 05/2017

Acoustic Process Control for Laser Material Processing

Authors:

Balthasar Fischer, Wolfgang Rohringer, et al.

Contents:
  • New approach for in-line process monitoring for laser material processing
  • Emitted ultrasound reveals information about laser weld penetration depth
PDF
