Publications

Proceedings of LANE 2020 Erlangen

In situ process monitoring by optical microphone for crack detection in Laser Metal Deposition applications

Authors:

Camilo Prieto, Roberto Fernandez, et.al.

Contents:
  • Contact-free crack detection in Laser Metal Deposition (LMD) applications in collaboration with AIMEN successfully documented
  • XARION’s optical microphone, Eta250 Ultra, enabled real-time monitoring of crack and process signals of additive manufacturing applications
PDF

Journal of Composite Materials 06/2020

Qualitative comparison of non-destructive methods for inspection of carbon fiber-reinforced polymer laminates

Authors:

Janes Ruz, Alex Gustschin, et.al.

Contents:
  • Thirteen different non-destructive methods were compared and qualitatively characterized
  • XARIONs Optical Microphone is the only couplant-free method that was tested that allowed an inspection in the MHz-range
  • The very good spatial resolution of the Optical Microphone was verified
PDF

Biomedical Optics Express 04/2020

Functional optical coherence tomography and photoacoustic microscopy imaging for zebrafish larvae

Authors:

Richard Haindl, Abigail J. Deloria, et.al.

Contents:
  • A non-invasive imaging technology with the optical microphone is applied to Zebrafish larvae
  • Results demonstrate the capability to image not only the shape of smallest micron-sized vessels, but also blood flow and oxygen saturation
  • These parameters are essential in preclinical physiological and drug response studies
PDF

Journal of Nondestructive Evaluation 03/2020

Local Ultrasonic Resonance Spectroscopy: A Demonstration on Plate Inspection

Authors:

Janez Rus, Christian Grosse

Contents:
  • Local ultrasonic resonance spectroscopy (LURS) is a new approach to ultrasound signal analysis
  • XARION’s ultrasonic sensor was used for a LURS scan of a carbon fiber reinforced polymer plate. An advantage in characterizing the features of the specimens could be demonstrated
PDF

Proceedings of SPIE LASE 2020 San Francisco

Air-coupled membrane-free optical microphone and optical coherence tomography keyhole measurements to setup welding laser parameters

Authors:

Nicolas Authier, Enzo Touzet, et. al.

Contents:
  • Accurate measurements of the welding depth could be demonstrated with XARION's sensor by the French Alternative Energies and Atomic Energy Commission (CEA)
  • The combination of Optical Coherence Tomography with airborne ultrasound data from an Optical Microphone is a promising match for in-line monitoring of laser welding processes
PDF

Proceedings of Transducers 2019 Berlin

Display Compatible PMUT Array for Mid-Air Haptic Feedback

Authors:

Alexandre Halbach, Pieter Gijsenbergh, et al.

Contents:
  • Optical microphone used in development of mid-air haptic feedback sensors integrated into displays
  • Sound pressure characterization of 32 x 32 element piezoelectric micromachined ultrasound transducer (PMUT)
PDF

Sensors 07/2019

Intensity Modulated Photothermal Measurements of NO2 with a Compact Fiber-Coupled Fabry–Pérot Interferometer

Authors:

Philipp Breitegger, Benjamin Lang, et al.

Contents:
  • Measurement of nitrogen dioxide concentrations in parts per billion
  • The optical microphone enables a miniaturized sensing concept, providing outstanding robustness against mechanical vibrations
PDF

Journal of Micromechanics and Microengineering  07/2019

Characterization of polymer-based piezoelectric micromachined ultrasound transducers for short-range gesture recognition applications

Authors:

Pieter Gijsenbergh, Alexandre Halbach, et al.

Contents:
  • The Interuniversity Microelectronics Centre investigated the use of polymer-based piezoelectric micromachined ultrasound transducers (PMUT) for short-range gesture recognition applications
  • During the course of the project the optical microphone was used to measure the pressure emitted by a single PMUT at various distances
PDF

Proceedings of SCMT5 2019 London

Material characterization via contact-free detection of surface waves using an optical microphone

Authors:

Wolfgang Rohringer, Nils Panzer, et al.

Contents:
  • Single-sided non-contact measurements of a spot-welded steel plate, an aluminium plate and on a sandstone sample
  • The results demonstrate the ability of XARION's technology on a wide range of surfaces and materials
PDF

Bachelor Thesis University Ravensburg-Weingarten

Acousto-optical Process Control for Laser Ablation and Laser Welding

Authors:

Chen Peng

Contents:
  • The optical microphone has proven effective and invaluable as a measurement instrument during laser processes.
  • The measurements obtained are useful in:
    • the automated calibration of the optimum focus spot of a laser beam,
    • controlling the laser ablation quality in a production line without modifying the workpiece, and
    • identifying keyhole formation (or lack thereof) during laser welding processes.
PDF
