Publications

13th CIRP Conference on Photonic Technologies  08/2024

Acoustic process monitoring during the structuring of diffusion media for fuel cells with Ultrashort Laser Pulses

Authors:

Christian Geigera, Pawel Garkushaa, Christian Bernauera, Simon Mehrla, Pascal A. Schirmerb, Michael F. Zaeha

Contents:
  •          Diffusion media in fuel cells can be optimized through laser structuring to improve their performance characteristics.
  •          An optical microphone was used to monitor the process during laser structuring.
  •          This paper demonstrated that acoustic data can be used to monitor the laser focus position as well as material transitions in the diffusion media during structuring.
13th CIRP Conference on Photonic Technologies

Wood Materal Science & Engineering  10/2024

Predicting wood moisture classes by sound frequency spectra and Explainable Machine Learning during milling

Authors:

Mehieddine Derbas, Timothy Mark Young, Stephan Frömel-Frybort, Hans- Christian Möhring & Martin Riegler

Contents:
  •          The moisture content in wood has a strong impact on the optimal process parameters during milling.
  •          In this work, wood milling was monitored by a novel optical microphone to distinguish between moisture classes (dried, conditioned, wet and frozen).
  •          Machine learning was applied to the selected spectral data to determine both the moisture classes and milling speed. The best model achieved an accuracy of 97.2%.
Wood Materal Science & Engineering

Journal of Laser Applications  03/2025

Layer detection in ultrashort pulsed multilayer laser ablation by analyzing ultrasonic process emission

Authors:

Christian Lutz, Cemal Esen, Ralf Hellmann

Contents:
  • Laser ablation is used for processing electronic applications (e.g. PCB)
  • This paper presents the detection of material transitions during laser ablation by analyzing acoustic data captured with an optical microphone.
  • The focus of this work was on the material transition between polyimide and copper. Due to the higher removal rate in polyimide compared to copper, a    significant increase in acoustic energy was detected at the material transition.
  •  In addition to detecting material transitions, a correlation between the emitted acoustic energy and layer thickness was observed.
Journal of Laser Applications

17th CIRP Conference on Intelligent Computation in Manufacturing Engineering (CIRP ICME ‘23)  08/2024

In-situ acoustic signals correlation of process parameters in laser powder bed fusion

Authors:

Levent Subasi, Soner Oren, Gokhan Dursun, Cagdas Sen, Akin Orhangul

Contents:
  • Laser powder bed fusion (LPBF) is a metal additive manufacturing technique in which repeatability is a major concern in quality results.
  •          An optical microphone was used to monitor the acoustic emission during the LPBF process.
  •          The analysis showed a strong correlation between the acoustic signals and the process parameters.
  •         This methodology allows for the evaluation of process flaws and overall quality.
17th CIRP Conference on Intelligent Computation in Manufacturing Engineering

Springer 03/2025

Handbook of Nondestructive Evaluation 4.0

Authors:

Norbert Meyendorf, Nathan Ida, et.al.

Contents:
  • This handbook is a comprehensive overview of advanced NDE technologies for use in many different industrial applications
  • XARION is represented with a chapter on its innovative automated spot-weld inspection technology
Link

Applied Sciences 10/2024

Acoustic Emission and Digital Image Correlation-Based Study for Early Damage Identification in Sandwich Structures

Authors:

Aitor García de la Yedra, Igor Erro, et al.

Contents:
  • Monitoring the quality of complex sandwich structures is difficult with common testing techniques for accessibility reasons
  • A novel approach to solve this issue is enabled by acoustic monitoring in the ultrasound regime with the Optical Microphone
  • The results from acoustic monitoring were compared to findings obtained with digital image correlation
  • It could be shown that early identification of structural damage is possible with the Optical Microphone
Link

Additive Manufacturing 01/2024

Healing of keyhole porosity by means of defocused laser beam remelting: Operando observation by X-ray imaging and acoustic emission-based detection

Authors:

Charlotte de Formanoir, Milad Hamidi Nasab, et al.

Contents:
  • In Laser Powder-Bed Fusion (LPBF) the unpredictable formation of defects such as pores can lead to compromised mechanical properties
  • Using XARION’s optical microphone a strategy for monitoring in-situ healing of pores through laser remelting was implemented
  • Acoustic signals acquired during laser remelting are temporally synchronized and analyzed with X-ray images to identify acoustic signatures of the pore healing event
  • The approach presented in this paper enables precise monitoring of defect healing during the LPBF process without the use of elaborate machine learning algorithms
PDF

SPIE. Photonics West 01/2024

Towards process control by detecting acoustic emissions during ultrashort pulsed laser ablation of multilayer materials

Authors:

C. Lutz, R. Sommerhuber, M. Kettner, C. Esen, R. Hellmann

Contents:
  • Ultra-short-pulsed laser ablation of thin multilayer materials can be monitored using XARION’s Eta450 Ultra optical microphone
  • It is possible to monitor the material transition between polymer and copper during laser ablation by observing a broad acoustic frequency spectrum between 100 kHz and 2 MHz in air, and by detecting a sudden change in acoustic energy
  • A direct correlation was found between increased detected acoustic energy and higher ablation rate
Link

Nature Communications 12/2023

Harmonizing sound and light: X-ray imaging unveils acoustic signatures of stochastic inter-regime instabilities during laser melting

Authors:

Milad Hamidi Nasab, Giulio Masinelli, et al.

Contents:
  • Laser Powder Bed Fusion Additive Manufacturing (LPBF AM) is a metal additive manufacturing process capable of directly producing intricate three-dimensional metallic components from CAD models
  • The present work deploys high-speed synchrotron X-ray imaging to scrutinize keyhole melting instabilities in LPBF and correlates these with the process’ acoustic emission (AE)
  • XARION’s optical microphone was used to measure airborne AE from the interaction zone between laser and material
  • The transition between conduction, stable keyhole, and unstable keyhole regimes, which leads to porosity formation and other instabilities, can successfully be discerned using the AE data
PDF

Nature Communications 11/2023

Ultrasonic barrier-through imaging by Fabry-Perot resonance-tailoring panel

Authors:

Chung Il Park, Seungah Choe, et al.

Contents:
  • Ultrasonic imaging through nearly impenetrable metal barriers or the human skull remains an unresolved challenge
  • Applying a Fabry-Perot resonance approach and resonance tailoring panels the authors show that ultrasonic transmission through otherwise impenetrable barriers can be achieved
  • XARION's optical hydrophone (Eta100L Ultra) was employed to capture ultrasonic signals in the experiments
  • The newly developed method enables almost equivalent image quality as without barriers and has the potential to improve ultrasonic imaging
PDF
